Surface Prep   >   Floor Grinders.

U.S.A. Dust Guard   Direct Drive Grinders - provide more torque, lower RPM and less Amp draw vs. Planetary Grinders ~ Perfect for large construction and residential projects operating from 120 volt power.

Click on the models for individual product information and please call us if you have any questions at, 412-687-5005, ext #2403.  To speak directly to our product specialist, call:  412-605-2992.









Made in the USA.HAWK GRINDERS - Direct Drive
Powers from 120V 20 Amp Circuit


  Hawk Concrete Floor Grinder, 10" & 13". Hawk Concrete Floor Grinder, 17" & 20". Hawk Concrete Floor Grinder, 26".
  10" & 13", 120v 17" & 20", 120v 26" 120v Dual Motor
  71 lbs 233 lbs 348 lbs
  HD, DIRECT DRIVE TORQUE for Concrete Grinding,
Coating Removal, Scarify Concrete
Virtually Maintenance Free - Extremely Durable
No Belts or Pulleys to Snap

  Small Rooms
Tight Spaces
High Production 26" Grinding Path




Direct Drive High-Torque vs. Planetary Grinders

HD, All American Components Built into Every Hawk Grinder



Comparison between Direct Drive Gears & Planetary Gearbox --- in relation to energy consumption, maintenance, performance.

  • ENERGY CONSUMPTION --- EFFICIENCY.
    • Planetary, belt-driven gearbox
    • Direct Drive Gears - Helical-Cut, Metal Gears:  maximizes power, torque and energy effectiveness while minimizing amp draw and friction loss.

  • Helical-Cut, Metal Gears - Direct Drive System.MAINTENANCE --- CASE-HARDEN STEEL GEARS.
    Built like the transmission in a car, providing decades of life and uninterrupted service with less maintenance vs. a belt-drive gearbox.
    • Drive belts will wear and snapped at the most unfortunate times.  Realistically, case-harden steel gears are far superior than a fiber belt.
    • Not only do direct drive gears provide the advantage of driving the diamond plate with minimal power loss and amp draw, but zero maintenance and breakdowns are virtually assured.

  • PERFORMANCE --- WEIGHT & POWER.
    • Direct Drive:
      • The basic design of direct drive gears provides the highest production rate in its class
      • Majority of the grinder's weight is where it matters most, which is the grinding head
      • More power, more effective use of the power, and greater grinding pressure is delivered using less weight.
      • How powerful and effective is a direct drive, high-torque grinder?  Rubber coatings are effectively removed vs. a belt-driven grinder whose belts will slip and/or break (especially notched belts.)
    • Planetary Gearbox:  Relies on belts to provide higher RPM, but lower torque:
      • Ideal for polishing applications
      • Effectiveness in grinding and coating removal is significantly diminished
      • Amp draw is three times greater than a direct drive grinder.

  • CONCLUSION:  Direct drive gears exhibit compelling advantages over a planetary gearbox in terms of energy efficiency, reduced amp draw and virtually zero maintenance requirements.  While a belt-driven planetary gearbox excels in high RPM and low-torque scenarios (i.e. polishing), its performance in grinding and coating removal falls short and its amp draw is substantially higher.

I trust that this information will assist you in making an informed decision regarding the appropriate gear system for your specific needs.  Should you have any further questions or require additional clarification, please do not hesitate to reach out.
