Allmand Maxi-Power 25

$32,000.00
Maxi-Power™ 25 Mobile Generator

Maximize the power of your job site with the Maxi-Power™ 25 Mobile Generator.  With a frequency switch for flexibility of jobsite power needs and 15" tires for longer wear and greater towing capabilities.  This unit also has forklift pockets, which set it apart from the others in the lineup.

Included:  Artic Heating Package --- keeps critical components warm in cold-weather situations.  Ensures reliable starting and efficient operation in freezing temperatures by preventing hard starts, reduced battery performance, and unnecessary engine wear.

FEATURES

• Fluid Containment System (FCS) - Holds 110% of all on-board fluids

• Large Capacity Fuel Tank - Allows over 24 hour run time at full load

• EFPA (Electric Fuel Primer & Air-Bleed) Pump - No need to bleed air if fuel runs out

• Oversized Electrical Lugs - Easy to connect leads (with no copper shaving)

• Curbside Fluid Maintenance - Ease of serviceability

• Lockable Switch / Voltage Selector - Consistency on jobsite, keeping it where it was set by the operator on-site

• Switch-Able Voltage:

  • Single Phase – 120 V / 240 V

  • Three Phase - 120 V / 208 V or 277 V / 480 V

• Standard Programmable Start / Stop for Standby Applications

• Standard External Fuel Connections

• Trailer – Poly Fenders with Steel Steps & Removable Steel Rear Bumper

• Model:  MP25

• Engine Brand:  Isuzu

• Engine Model:  4LE2T

• Engine Tier:  4 Final

• Output @ Rated Speed (1,800 RPM) - HP:  33

• Standby Power - 27,000 Watts

• Prime Power - 25,000 Watts

• Battery (V):  12

• Voltage Regulation Percentage:  0.50%

• Amperage:

  • 1-Phase 120 V (A): 60 x 2

  • 1-Phase 240 V (A): 60

  • 3-Phase 120 V / 208 V (A): 69

  • 3-Phase 277 V / 480 V (A): 30

• Excitation:  Brushless with AVR

• Armature Connection Layout:  Star with Neutral/Zig/Zag

• Insulation:  Class H4

• Integral Fuel Tank Capacity (gal):  52

• Runtime @ Full Load (hrs):  31+

• Main Breaker Size (Amps):  100 (80%)

• Sound Level @ 23 ft. (No Load) - dBA:  63

• Engine Oil Change Interval (hrs):  500

• Engine Fuel Filter Change Interval (hrs):  500

• Dry Weight (lbs):  2,425

• Operating Wet Weight (lbs):  2,780

• Trailer Weight (lbs):  531.4

• Trailer GVWR (lbs):  2,900

• Height With Towing Frame (in):  72

• Length With Towing Frame (in): 123.3

• Width With Towing Frame (in):  54.8
